2D Industrial handheld Wired Barcode Scanner XB-D60

2D Industrial handheld wired barcode scanner with Green LED Light, fast and accurate scanning ability, the speed up to 120 FPS. It is capable of scanning 1D 2D code of PDF417, QR code, Data Matrix, Aztec Code etc.


  • Item NO.:

    XB-D60
  • Payment:

    EXW/FOB
  • Product Origin:

    Guangzhou
  • Color:

    Black and Green
  • Shipping Port:

    Guangzhou/Shenzhen
  • Lead Time:

    7-15days
  • Product Details



New design 2D Industrial handheld barcode scanner with Green LED Light

XB-D60 is Syble new design 2D Industrial handheld wired barcode scanner with Green LED Light,has innovative design and competitive factory price. Strong recognition of folding code, stain code, vacuum packaging bar code etc. Placing the scanner on the stand then switch to the auto-sensing mode automatically,no need to rely on setting codes.


Product Feature

•Support various barcodes such as WeChat and Alipay

•New decoding chip for interpreting various 1D and 2D barcodes

•Support Chinese direct transmission of QR code

•Plug and play, easy to set up and quickly match

The loud beep for easily operate in the noisy circumstances

•Wire life more durable


Specification

Performance Parameters

Light Sources

 (Aimer)RED color LED, (lllumination)White color LED

Supported Symbologies

ID: Codabar, Code 39, Code 32 Pharmaceutical(PARAF), Interleaved 2 of 5,NEC 2 of 5, Code 93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA,

Matrix 2 of 5, Code 11, Code 128, GS1-128, UPC-A, UPC-E, EAN/JAN-8,EAN/JAN-13, MSI, GS1 DataBar Omnidirectional, GS1 DataBar Limited,GS1 DataBar Expanded, China Post(Hong Kong 2 of 5), Korea Pos.
2D: Codeblock A, Codeblock F, PDF417, Micro PDF417, GS1 Composite Codes, QR Code, Data Matrix, MaxiCode, Aztec, HANXIN.

Image (Pixels)

640pixels (H) x 480 pixels (V)

Field of View:

39°(Horizontal), 29°(Vertical)

Print Contrast:

20% minimum reflective difference

Motion Tolerances:

> 1m/s

Scan Angle

Yaw±65°, Rotation 360°, Pitch±65°

Depth of scan field

Code39(5mil): 7-16cm, Code39(13mil): 7-32cm

QR code (15mil): 3-18cm, Codel28(20mil): 6-35cm

Error Rate

1/5million

Interface

USB,USB-COM,RS232

Physical  Parameters

Dimensions

83.5mm*65.7mm*174.8mm

Material

ABS+PC

Cable Length

1.8M

Environmental Parameters

Operating Temperature

-20℃ ~60℃

Storage Temperature

-30℃~70℃

Relative Humidity

5%~95% RHNon-condensing

Ambient lighting

0~100000LUX

Electronic Parameters

Working Voltage

DC5V±5%

Operating Current

300mA

Standby Current

35mA


 FAQ:

Q1: Is OEM or ODM available?

Yes. Syble is the professional manufacturer and are capable of manufacturing the products based on customer requirements. All the hardware and software are 100% designed by us, we are very flexible to offer the ODM/OEM service.

Q2: Why so competitive?

With many years experience, Syble owned a large domestic market and is the best-seller in China. Large quantity reduce the raw material cost directly.What’s more, mature technology is the important factor to save cost.

Q3: How about the quality?

Professional QC team and testing machine .All the products pass CE,FCC,ROSH, etc.

Q4: How to control the performance stable?

Syble takes the flow line production in the whole processing. Every product should have to be tested 4 times at least before it delivery.

Q5. What’s the warranty policy for the barcode scanners?

Syble provide 1 month replacement and 24 months maintenance warranties. Barcode scanners can be replaced during the first month if the technical and quality problem. During warranty, free and quick advice for repairing, free spare parts for replacement if necessary  or new barcode scanners replacement in the next order.


Value-added services:
1. Provide long time maintenance services
2. Provide extended warranty as required
3. Provide the regular routine maintenance services
