1D/2D Presentation Barcode Scanners stationary In Counter Barcode Scanner

Specifications: Presentation Barcode Scanner

Performance Parameters

Light Sources

SXGA-W(Width1280*high1024) Ratio(5:4)

Supported symbologies

1D: EAN-8,EAN-13,EAN-132 add-on,EAN-135add-on,ISSN,ISBN,UPC-A,UPC-E,

Code 11,Code 32,Code 39,Code 93,Code 128,Codabar,Industrial 2 of 5,

Interleaved 2 of 5,Matrix 2 of 5,ISBT-128、GS1-128,GS1 DataBar(RSS14),

GS1 DataBar Limited,GS1 DataBar Expanded.

2D: PDF417,MicroPDF417,QR-code、Micro QR,Data Matrix,QR,Aztec.

Scan Range

3mil(Code39) 0cm~8cm; 5mil 0cm~21cm;

13mil(UPC-13) 0cm~43cm; 20mil(QR Code) 1cm~35cm

System compatibility

Linux、Android、Windows XP、7、8、10、MAC

Minimum recognition accuracy

Code 39 4mil

Motion tolerance

3.8meters/second

Scan Mode

Continuous Scanning

Print contrast

20%

Recognition angle range

Turn angle ±360°, elevation angle ±60°, declination angle ±70°

Mutual Move

Indicator light: Red and blue dual color indicator light: Blue light flashing code reading prompt, blue light power indicator; Red light: turn off QR code reading.

Buzzer: start prompt, read code prompt;Key: switch three tones; QR code switch.

Interface

USB(Drive-Free), RS232, USB-COM

Physical  Parameters

Dimensions

152mm*87mm*152mm

Weight

390g

Material

ABS+PC

Cable length

2M

Environmental Parameters

Operating Temperature

-20℃ - 55℃

Storage Temperature

-20℃-60℃

Humidity

5% to 95% RH.Non-condensing

Shock Resistance

Withstands multiple times 1.5 meters drops to concrete

Electrical Parameters

Voltage

DC5V±5%

Current

Standby current 160mA; Working current 310mA
